625-4189 Impeller Rebuild Service Kit - For Gen 4 and Gen 5/6 Rev. 2 Hardin Stainless Pumps - Mercury Replacement
This impeller kit is a rebuild service kit for the Hardin Marine stainless impeller housing 625-4178 and stainless pumps 625-4110 and 625-4118 . This kit comes with new wear plates , O-rings, and impeller. Rev. 2 Version for pumps manufactured from 01/2013
Which Rebuild kit do I need?
Rev. 1 pumps have a 1/8" drain plug in the rear housing and a slotted front wear plate.
Rev. 2 pumps have no drain plug and a solid front wear plate.
Mercury
This impeller kit is a rebuild service kit for the Hardin Marine stainless impeller housing 625-4178 .
Kit includes:
- (1)Impeller
- (2) Wear Plate
- O-rings
|
|
625-4179 Impeller Rebuild Service Kit - For Gen 4, Gen 5/6, Rev. 1 Hardin Stainless Pumps - Mercury Replacement
This impeller kit is a rebuild service kit for the Hardin Marine stainless impeller housing 625-4178 and stainless pumps 625-4110 and 625-4118 . This kit comes with new wear plates , O-rings, and impeller. Rev. 1 Version for pumps manufactured up to 12/2012.
Which Rebuild kit do I need?
Rev. 1 pumps have a 1/8" drain plug in the rear housing and a slotted front wear plate.
Rev. 2 pumps have no drain plug and a solid front wear plate.
Mercury
This impeller kit is a rebuild service kit for the Hardin Marine stainless impeller housing 625-4178 .
Kit includes:
- (1)Impeller
- (2) Wear Plate
- O-rings
See here for individual replacement parts.
|
|
625-4178 Stainless Steel "Extreme" Sea Pump Overhaul Kit
Finally a Sea Water Pump repair kit designed to do the job once and for all and will last a lifetime. Hardin Marine has designed an all new 316L stainless steel water pump impeller housing to replace the cheap factory plastic style housings used on original equipment applications. These impeller housings won't corrode, erode, or crack and fall apart like original equipment units. The one piece rear impeller housing features a unique rear housing that has 1" NPT female inlet/outlet ports so that a wide range of fitting and hose connections can be used for ease of installation. If your looking to do this job once and for all this could possible be the last sea water pump repair kit you ever buy look no further as this is the finest direct replacement sea pump repair kit on the market today.
The kit includes:
- O-rings
- Impeller
- Stainless Wear Plates
- Polished Stainless Steel Sea Pump Body
- Bolts, Nuts & Washers
This kit replaces:
- Quicksilver – 46-72744-A32
- Mercury – 46-807151A14
- Mercruiser – 46-807151-A2
- Mercury – 46-807151-A8
- Mercury – 46-807151-A9
- Sierra - 18-3150
Note: Requires Fittings. See related items.
See here for individual replacement parts.
|
|
525-46-807151A14 Plastic Housing Body and Impeller Kit Replaces Mercruiser 46-807151A14
DIRECT OEM Factory Replacement Mercruiser Parts for: 46-807151A7 and 46-807151A14
|
|
700-12088 Brass Housing Seawater Pump Service Kit- Fits GLM one piece brass body pump- Fits Mercruiser one piece pump replaces MerCruiser part # 47-807151A14 Brass Housing
Fits GLM one piece brass body pump
Fits Mercruiser one piece pump
|
|
700-12280 Upper Seawater Pump Housing Impeller Kit replaces MerCruiser part # 46-96148T8
For Drive Mounted- MC-1 / R / MR / Alpha One
Kit Contains:
| Part # |
MerCruiser # |
Description |
|
Part # |
MerCruiser # |
Description |
| 700-12410 |
48-96148A1 |
Housing |
|
700-12510 |
32435 |
Wear Plate |
| 700-12820 |
23-29804 |
Guide Tube |
|
700-21330 |
25-30271 |
Slinger |
| 700-31010 |
27-85608-1 |
Gasket |
|
700-31020 |
27-858524 |
Gasket |
| 700-31030 |
27-32438 |
Gasket |
|
700-31040 |
27-856704 |
Gasket |
| 700-31050 |
27-42631-1 |
Gasket |
|
700-31170 |
12-20260 |
(2)Gasket |
| 700-81160 |
25-30613 |
O-ring |
|
700-81390 |
25-90011 |
O-ring |
| 700-82250 |
25-30224 |
O-ring |
|
700-82260 |
25-33145 |
O-ring |
| 700-85140 |
26-45577-1 |
Seal |
|
700-89840 |
47-89984T4 |
Impeller |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
676-18-3017 Additional Details: - Fits: MCM & outboard applications
- Uses: a brass insert
Use With: Interchanges/ReplacesChrysler/Force/US MarineGLMMalloryMercruiser Stern Drive- 47-30221
- 47-65960
- 47-89984
- 47-89984T4
Mercury Marine- 47-30221
- 47-65960
- 47-85460
- 47-89984
- 47-899842
- 47-899844
- 47-89984T3
- 47-89984T4
|
|
625-4206 Sea Pump Tool Stud Kit
|
|
625-1231 O-Ring Replacement for Nicson style pumps
|
|
