SSM Six - All Serials - Tool List (SSM Six)
Section Drawing: (Hover or click to view larger)
Other Sub-Sections:
- Cable Actuator Components, Design-I
- Cable Actuator Components, Design-II
- Connector Block And Hydraulic Hoses
- Gear Housing Assembly (Dry Sump Six-NXT1 - Driveshaft)
- Gear Housing Assembly (Dry Sump Six-NXT1 - Propshaft)
- Gear Housing Assembly (SSM Seven - Driveshaft-Propshaft)
- Gear Housing Assembly (SSM Six - Driveshaft)
- Gear Housing Assembly (SSM Six - Propshaft)
- Gimbal Housing Assembly (Close Couple)
- Gimbal Housing Assembly (Driveline)
- Gimbal Ring And Bell Housing Assembly (With Trim Sensor)
- Gimbal Ring And Bell Housing Assembly (Without Trim Sensor)
- Inner Transom Plate Assembly (Dry Sump Six)
- Inner Transom Plate Assembly (SSM Six And Seven)
- Prop Ventilation Kit, SSM Six
- Spacer Kit (.500 Inch Thru 3.00 Inch)-SSM Six
- Spacer Kit (1.00 Inch Thru 3.00 Inch)-SSM Seven
- Spacer Kit (5.75 Inch)-SSM Six
- Steering Cylinder Assembly
- Tool List (Dry Sump Six-NXT1 SSM Six - Lower)
- Tool List (Dry Sump Six-NXT1 SSM Six - Transom)
- Tool List (Dry Sump Six-NXT1 SSM Six - Upper)
- Tool List (SSM Seven)
- Tool List (SSM Six)
- Trim Cylinder Assembly (With Trim Sensor Plate)
- Trim Cylinder Assembly (Without Trim Sensor Plate)
- Trim Pump Assembly (843017T03)
- Trim Pump Assembly (846860T1)
- Trim Pump Components (Design I - 846859A1)
- Trim Pump Components (Design II - 846859A1)
- U Joint Housing Assembly (Dry Sump Six-NXT1 SSM)
- U Joint Housing Assembly (SSM Seven)
- U Joint Housing Assembly (SSM Six - Early Style)
- U Joint Housing Assembly (SSM Six - Late Style)
| Ref. | OEM Part # | Hardin # | Mallory # | GLM # | Other # | Description | Num Req. | Superceded From | Special Notes |
| - | 91-847427 | PRESSING TOOL, Expansion Plug | 1 | ||||||
| - | 91-847443 | REMOVAL TOOL, Bearing Cup | 1 | ||||||
| - | 91-847444 | GAGE TOOL, Steering | 1 | ||||||
| - | 91-8M0010286 | SOCKET TOOL | 1 | 91-847449 | |||||
| - | 91-847454 | HOLDER TOOL, Driveshaft | 1 | ||||||
| - | 91-847456 | SOCKET TOOL, Torpedo Retainer | 1 | ||||||
| - | 91-847472 | DRIVER TOOL, Bearing Cup | 1 | ||||||
| - | 91-847481 | CLAMP TOOL | 1 | ||||||
| - | 91-847566 | PRESSING TOOL | 1 | ||||||
| - | 91-847567 | PRESSING TOOL | 1 | ||||||
| - | 91-847570 | EXTENSION TOOL, Slide Hammer | 1 | ||||||
| - | 91-847572 | PRESSING TOOL | 1 | ||||||
| - | 91-847573 | PLATE TOOL, Rear | 1 | ||||||
| - | 91-847575 | INSTALLER TOOL | 1 | This Part is No Longer Available | |||||
| - | 91-847576 | DRIVER TOOL, Bearing Cup | 1 | This Part is No Longer Available | |||||
| - | 91-847581 | REMOVAL TOOL | 1 | This Part is No Longer Available | |||||
| - | 91-847582 | WRENCH TOOL, Retainer Nut | 1 | This Part is No Longer Available | |||||
| - | 91-847583 | GAGE TOOL | 1 | This Part is No Longer Available | |||||
| - | 91-847584 | GAGE TOOL, Pinion | 1 | This Part is No Longer Available | |||||
| - | 91-8M0010286 | SOCKET TOOL, Tailstock Spline | 1 | 91-847585 | |||||
| - | 91-847588 | SOCKET TOOL, Driveshaft | 1 | This Part is No Longer Available | |||||
| - | 91-847590 | JAW TOOL | 1 | This Part is No Longer Available | |||||
| - | 91-848479A01 | GAGE ASSEMBLY TOOL, Upper Driven Gear Position | 1 |
