135 VERADO 4-STROKE 4 CYL - Serial 0P419487 Thru 0P464487 - Powerhead Gasket Set Components
Section Drawing: (Hover or click to view larger)
Other Sub-Sections:
- Accessories
- Adaptor Plate Hose Routings
- Adaptor Plate-Lower
- Alternator/Belt Tensioner Mounting
- Charge Cooler/Intake Manifold
- Charge Cooler/Intake Manifold Hose Routings
- Crankshaft, Pistons and Connecting Rods
- Cylinder Block
- Cylinder Head and Camshaft
- Driveshaft Housing
- Electrical Box Components
- Fuel Supply Module
- Gear Housing(Driveshaft)(Standard/Counter Rotation)
- Gear Housing, Propeller Shaft - Counter Rotation
- Gear Housing, Propeller Shaft - Standard Rotation
- Induction Components
- Oil Pump/Adaptor Plate-Upper
- Port Cylinder Block Components
- Power Trim Components
- Powerhead Gasket Set Components
- Rear Cowl
- Shift Components (Serial Number 1B290522 and Below)
- Shift Components (Serial Number 1B290523 and Up)
- Starboard Cylinder Block/Oil Cooler
- Starter Motor
- Steering Cylinder Assembly
- SuperCharger
- Swivel Bracket and Steering Arm
- Tools
- Tools
- Top Cowl
- Transom Brackets
| Ref. | OEM Part # | Hardin # | Mallory # | GLM # | Other # | Description | Num Req. | Superceded From | Special Notes |
| - | 27-896142A07 | GASKET SET, Powerhead | 1 | 896142A06 | |||||
| - | 25-892077 | O-RING, Fitting Assembly | 1 | ||||||
| - | 25-62701 | O-RING, Fitting Assembly | 2 | ||||||
| - | 25-884409 | O-RING, Cylinder Block Dowl Pin | 1 | ||||||
| - | 25-884423 | O-RING, Cylinder Block Dowl Pin | 1 | ||||||
| - | 27-8M0024565 | GASKET, Head, Cylinder Head to Block | 1 | 896277006 | |||||
| - | 27-896142 | GASKET, Block to Adaptor | 1 | ||||||
| - | 25-90196 | O-RING, (.921 x .139), Oil Plug Assembly | 1 | ||||||
| - | 25-898836 | O-RING, Orange, Tensioner End Cap | 1 | 880631001 | |||||
| - | 26-8M0032912 | SEAL, Top Main Bearing | 1 | 8805251 | |||||
| - | 25-897134 | O-RING, (1.051 x 1.070), Adaptor Plate-Oultet | 1 | ||||||
| - | 25-897135 | O-RING, (.864 x .070), Adaptor Plate-Inlet | 1 | ||||||
| - | 26-8M0033928 | SEAL, Oil, Adaptor Plate | 1 | 884461 | |||||
| - | 26-884462 | SEAL, Water, Water-Adaptor Plate | 2 | ||||||
| - | 25-26317 | O-RING, Dump Fitting | 2 | ||||||
| - | 25-38780 | O-RING, Oil Pick-Up Tube | 1 | ||||||
| - | 27-895822 | GASKET, Oil Sump | 1 | ||||||
| - | 27-889561 | GASKET, Poppet | 1 | ||||||
| - | 26-880629 | SEAL, Exhaust Tube | 1 | ||||||
| - | 26-888593 | SEAL, Oil Sump Plug | 1 | ||||||
| - | 25-892445 | O-RING, Water Tube | 1 | ||||||
| - | 25-90196 | O-RING, (.921 x .139), Water Tube Coupling | 1 | ||||||
| - | 25-21836 | O-RING, (.796 x .139), Water Tube Coupling | 1 |
