Ref. | OEM Part # | Hardin # | Mallory # | GLM # | Other # | Description | Num Req. | Superceded From | Special Notes |
- | 892557A02 | STEERING HELM KIT, Standard (32 cc) | 1 | ||||||
- | 892380A02 | STEERING HELM KIT, Standard (40 cc) | 1 | ||||||
- | 892558A02 | STEERING HELM KIT, Standard (50 cc) | 1 | ||||||
1 | 892557T01 | HELM, Standard (32 cc) | 1 | ||||||
1 | 892380T01 | HELM, Standard (40 cc) | 1 | ||||||
1 | 892558T01 | HELM, Standard (50 cc) | 1 | ||||||
2 | 25-627021 | O-RING, (.301 x .070) | 2 | ||||||
3 | 25-48171 | O-RING, (.364. x .070) | 2 | ||||||
4 | 28-893394 | KEY, With Lock Tab (6.35 mm) | 1 | ||||||
5 | 10-4008875 | SCREW, (M6 x 75) | 4 | ||||||
5 | 10-4008850 | SCREW, (M6 x 50) | 4 | ||||||
6 | 11-826709121 | NUT, (.625-18) Stainless Steel | 1 | ||||||
7 | 892328T | COVER, Helm | 1 | ||||||
8 | 10-896842 | SCREW, (M6 x 14) | 4 | ||||||
9 | 892327 | PLATE, Helm Backing | 4 | ||||||
9 | 892327 | PLATE, Helm Backing | 3 | ||||||
9 | 892327 | PLATE, Helm Backing | 2 | ||||||
10 | 11-401196 | NUT, (M6) | 4 |
