2.5L EFI and EFI-OFFSHORE - Serial 0G857000 Thru 0T999519 - Powerhead Gasket Set Components

Section Drawing: (Hover or click to view larger)

Untitled Document
Ref. OEM Part # Hardin # Mallory # GLM # Other # Description Num Req. Superceded From Special Notes
- 27-849770A1         GASKET SET, Engine 1
0 26-94219         SEAL, Fuel Injector 6
0 27-993163         GASKET, Air Inlet 1
0 27-8475252         GASKET, Divider Plate 1
0 26-8147542         SEAL, Divider Plate 1
0 27-889072         GASKET, Cover 1
0 27-8231422         GASKET, Cylinder Block 2
0 25-54030         O-RING, (2.987 x .103), Cylinder Block 1
0 26-41953         SEAL, Cylinder Block 1
0 26-41953         SEAL, Lower End Cap 2
0 27-11338         GASKET, Cylinder Block 2
0 25-62700         O-RING, (3.237 x .103), Lower End Cap 1
0 26-849616         SEAL, Cylinder Head 2
0 25-817574         O-RING, Cylinder Head 6
0 27-62386001         GASKET, Cover 2 62386
0 27-127754         GASKET, Cylinder Head Plate 1
0 65800         PACKING, Crankshaft Carrier 1
