150 and 200 EFI Pro Max and Super Mag - Serial 0G610050 Thru 0G856999 - Starter Motor

Section Drawing: (Hover or click to view larger)

Untitled Document
Ref. OEM Part # Hardin # Mallory # GLM # Other # Description Num Req. Superceded From Special Notes
- 50-893893         STARTER MOTOR ASSEMBLY 1 79472
1 90645         DRIVE KIT 1
2 13310T1         PINION ASSEMBLY, Drive 1 75661
3 75660         PLATE 1
4 10-74968         BOLT 2
5 NSS         Washer (AMERICAN BOSCH #WA3122) 1   Not Sold Separate
6 79216         ARMATURE 1
7 898265016         BRUSH/SPRING KIT 1 75384
8 898265014         HOLDER 2 61787
9 NSS         Screw (AMERICAN BOSCH #02441-22-SC-30SM) 2   Not Sold Separate
10 15386001         END CAP 1 15386
